36V 60Ah Trolling Motor LiFePO4 Battery CP36060 Battery
36V 60Ah LiFePO4 Trolling Motor Battery | Ideal for Commercial & Recreational Fishing Boats
This 36V 60Ah LiFePO4 Trolling Motor Battery is designed for commercial fishing fleets, marine equipment suppliers, and boat manufacturers seeking a durable, eco-friendly power solution. With over 4000 deep cycles, fast charging, and a lightweight design, it ensures long-lasting, reliable performance for demanding marine applications.
Life cycles >4000 cycles
Bluetooth monitoring
PROPOW Marine Batteries | Reliable Power for Your Fleet
At PROPOW Energy, we provide high-performance LiFePO4 marine batteries tailored to meet the demands of commercial vessels. Designed for efficiency, reliability, and sustainability, our batteries are ideal for powerboats, fishing boats, yachts, and all types of vessels requiring superior energy solutions.
| Model | Rated Voltage | Rated Capacity | Battery Energy | Max. Charge Voltage | Cut-off Voltage | Charge Current | Discharge Current | Dimension (mm) | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 12V 100Ah | 12.8V | 100Ah | 1280Wh | 14.6V | 10V | 100A | 100A | 329*172*214 | 12.7kg |
| 24V 50Ah | 25.6V | 50Ah | 1280Wh | 29.2V | 20V | 50A | 100A | 260*168*209 | 12kg |
| 24V 100Ah | 25.6V | 100Ah | 2560Wh | 29.2V | 20V | 100A | 100A | 345*190*245 | 21kg |
| 36V 60Ah | 38.4V | 60Ah | 2304Wh | 43.8V | 30V | 60A | 120A | 329*172*214 | 17.2kg |
| 48V 30Ah | 51.2V | 30Ah | 1536Wh | 58.4V | 40V | 30A | 100A | 260*180*247 | 14.5kg |
| 48V 150Ah | 48V | 150Ah | 7200Wh | 54.75V | 37.5V | 100A | 100A | 640*245*220 | 49.5kg |
| 48V 105Ah | 51.2V | 105Ah | 5376Wh | 58.4V | 40V | 100A | 200A | 472*312*243 | 45kg |
| 48V 160Ah | 51.2V | 160Ah | 8192Wh | 58.4V | 40V | 100A | 200A | 643*327*231 | 72kg |
| 48V 210Ah | 51.2V | 210Ah | 10752Wh | 58.4V | 40V | 100A | 250A | 690*335*275 | 90kg |
| 72V 105Ah | 73.6V | 105Ah | 7728Wh | 83.95V | 57.5V | 100A | 200A | 559*302*273 | 67kg |
| 96V 50Ah | 96V | 50Ah | 4800Wh | 109.5V | 75V | 50A | 100A | 590*345*180 | 46kg |
| 96V 105Ah | 102.4V | 105Ah | 10752Wh | 116.8V | 80V | 100A | 250A | 880*350*273 | 92kg |
Power Your Fleet with PROPOW Energy
PROPOW Energy’s LiFePO4 marine batteries provide the **reliable, long-lasting power** you need for your **commercial vessels**. With multiple voltages available, our solutions are built to withstand the harshest marine environments and help **reduce operational costs** and **maximize uptime**. Invest in sustainability and performance today.
36V 60Ah Trolling Motor LiFePO4 Battery CP36060 Battery Parameter
| Item | Parameter |
|---|---|
| Nominal Voltage | 38.4V |
| Rated Capacity | 60Ah |
| Energy | 2304Wh |
| Cycle Life | >4000 cycles |
| Charge Voltage | 43.8V |
| Cut-Off Voltage | 30V |
| Charge Current | 60A |
| Discharge Current | 60A |
| Peak Discharge Current | 120A |
| Working Temperature | -20~65 (℃)-4~149(℉） |
| Dimension | 329*171*215mm |
| Weight | 16.7Kg |
| Package | One Battery One Carton, Each Battery Protected Well when package |
Advantages
High Energy Density
> This 36 volt 60Ah Lifepo4 battery provides 60Ah capacity at 36V, equivalent to 2304watt-hours of energy. Its compact size and light weight make it suitable for applications where space and weight are limited.
Long Cycle Life
> The 36V 60Ah Lifepo4 battery has a cycle life of 2000 to 5000 times. Its long service life provides a durable and sustainable energy solution for electric vehicles, solar energy storage and critical backup power.
Safety
> The 36V 60Ah Lifepo4 battery utilizes inherently safe LiFePO4 chemistry. It does not overheat, catch fire or explode even when overcharged or short circuited. It ensures safe operation even in harsh conditions.
Fast Charging
> The 36V60Ah Lifepo4 battery enables both rapid charging and discharging. It can be fully recharged in 3 to 6 hours and provides high current output to power energy-intensive equipment and vehicles.
Waterproof
Switched to a waterproof battery for your fishing boat, and it’s a game-changer! It’s incredibly reassuring to know that your battery can withstand splashes and moisture, ensuring you have reliable power no matter the conditions. It’s made your time on the water much more enjoyable, and feel confident in its durability. Definitely a must-have for any avid fisherman!"
BT Technology to Monitor Battery
Monitor the battery status in hand, you can check the battery charge, discharge, current, temperature, cycle life, BMS parameters, etc.
Remote diagnosis and upgradation of BMS
No need to worry about after-sales issues with remote disgosis and control function. Users can send the historical data of the battery through the BT APP to analyze battery data and troubleshoot any issues, welcome to contact us. will share you vedio to know more about it.
NMEA 2000 Seamless Communication
Propow LiFePO4 battery supports optional NMEA 2000 integration, enabling effortless connection and smart control within modern marine systems. Built for reliability and ready for seamless data communication, it’s the ideal power solution for advanced trolling motors and onboard electronics.
Why choose Batteries for Marine
*Longer cycle life: 10 years design lifespan, LiFePO4 batteries are specifically designed to replace lead-acid batteries, making them an ideal choice.
*Equipped with an intelligent Battery Management System (BMS), there is protection against overcharge, over-discharge, over-current, high temperatures, and short circuits.
Why Our Power LiFePO4 Batteries
-
10 Years Battery Life
Long battery design life
01 -
5 Years Warranty
Long warranty
02 -
Ultra Safe
Built-in BMS protection
03 -
Lighter Weight
Lighter than lead acid
04 -
More Power
Full capacity, more powerful
05 -
Fast Charge
Support quick charge
06
-
Grade A Cylindrical LiFePO4 Cell
Each cell is Grade A level, clarified as per 50mah and 50mV, bulit-in safe valve, when the internal pressure is high, it would automatically open to protect battery. -
PCB Structure
Each cell has separate circuit, has fuse for protection, in case one cell is broken, the fuse will cut-off automatically, but the complete battery will still working smoothly. -
Expoxy Board Above BMS
BMS fixed on expoxy board, the expoxy board is fixed on PCB, it is very robust struture. -
BMS Protection
BMS has protection from over-charging, over discharging, over current, short circuit and balance, could pss high current, intelligient control. -
Sponge Pad Design
Sponge (EVA)around the module, better protection from shaking, vibration.
PROPOW Marine Batteries | Reliable Power for Your Fleet
At PROPOW Energy, we provide high-performance LiFePO4 marine batteries tailored to meet the demands of commercial vessels. Designed for efficiency, reliability, and sustainability, our batteries are ideal for powerboats, fishing boats, yachts, and all types of vessels requiring superior energy solutions.
| Model | Rated Voltage | Rated Capacity | Battery Energy | Max. Charge Voltage | Cut-off Voltage | Charge Current | Discharge Current | Dimension (mm) | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 12V 100Ah | 12.8V | 100Ah | 1280Wh | 14.6V | 10V | 100A | 100A | 329*172*214 | 12.7kg |
| 24V 50Ah | 25.6V | 50Ah | 1280Wh | 29.2V | 20V | 50A | 100A | 260*168*209 | 12kg |
| 24V 100Ah | 25.6V | 100Ah | 2560Wh | 29.2V | 20V | 100A | 100A | 345*190*245 | 21kg |
| 36V 60Ah | 38.4V | 60Ah | 2304Wh | 43.8V | 30V | 60A | 120A | 329*172*214 | 17.2kg |
| 48V 30Ah | 51.2V | 30Ah | 1536Wh | 58.4V | 40V | 30A | 100A | 260*180*247 | 14.5kg |
| 48V 150Ah | 48V | 150Ah | 7200Wh | 54.75V | 37.5V | 100A | 100A | 640*245*220 | 49.5kg |
| 48V 105Ah | 51.2V | 105Ah | 5376Wh | 58.4V | 40V | 100A | 200A | 472*312*243 | 45kg |
| 48V 160Ah | 51.2V | 160Ah | 8192Wh | 58.4V | 40V | 100A | 200A | 643*327*231 | 72kg |
| 48V 210Ah | 51.2V | 210Ah | 10752Wh | 58.4V | 40V | 100A | 250A | 690*335*275 | 90kg |
| 72V 105Ah | 73.6V | 105Ah | 7728Wh | 83.95V | 57.5V | 100A | 200A | 559*302*273 | 67kg |
| 96V 50Ah | 96V | 50Ah | 4800Wh | 109.5V | 75V | 50A | 100A | 590*345*180 | 46kg |
| 96V 105Ah | 102.4V | 105Ah | 10752Wh | 116.8V | 80V | 100A | 250A | 880*350*273 | 92kg |
Power Your Fleet with PROPOW Energy
PROPOW Energy’s LiFePO4 marine batteries provide the **reliable, long-lasting power** you need for your **commercial vessels**. With multiple voltages available, our solutions are built to withstand the harshest marine environments and help **reduce operational costs** and **maximize uptime**. Invest in sustainability and performance today.
ProPow Technology Co., Ltd. is a company specialized in the research and development as well as manufacturing of lithium batteries. The products include 26650, 32650, 40135 cylindrical cell and prismatic cell, Our high-quality batteries find applications in various fields. ProPow also provides customized lithium battery solutions to meet the specific needs of your applications.
|
Forklift LiFePO4 Batteries |
Sodium-ion battery SIB |
LiFePO4 Cranking Batteries |
LiFePO4 Golf Carts Batteries |
Marine boat batteries |
RV Battery |
|
Motorcycle Battery |
Cleaning Machines Batteries |
Aerial Work Platforms Batteries |
LiFePO4 Wheelchair Batteries |
Energy Storage Batteries |
How To Customize Your Battery Brand Or OEM Your Battery?
Propow’s automated production workshop is designed with cutting-edge intelligent manufacturing technologies to ensure efficiency, precision, and consistency in lithium battery production. The facility integrates advanced robotics, AI-driven quality control, and digitalized monitoring systems to optimize every stage of the manufacturing process.
Quality Control
Propow places great emphasis on product quality control, covering but not limited to standardized R&D and design, smart factory development, raw material quality control, production process quality management, and final product inspection. Propw has always adhered to high-quality products and excellent services to enhance customer trust, strengthen its industry reputation, and solidify its market position.
We have obtained ISO9001 certification.With advanced lithium battery solutions, a comprehensive Quality Control system, and Testing system, ProPow has obtained CE, MSDS, UN38.3, IEC62619, RoHS, as well as sea shipping and air transport safety reports. These certifications not only ensure the standardization and safety of products but also facilitate import and export customs clearance.
