CPSE12120 12V 120Ah SEMI-SOLID STATE BATTERY
High-Performance Power Solution for Portable
Emergency and Storage Applications
Offers high energy density
Safety
ECO-friendliness and fast charging
An optimal choice for portable
Storage applications demanding lightweight
Long-lasting
Stable and sustainable power
Lifepo4 Battery
Bluetooth monitoring
Battery Parameter
| Item | Parameter |
|---|---|
| Nominal Voltage | 12.8V |
| Rated Capacity | 120Ah |
| Energy | 1536Wh |
| Cycle Life | >4000 cycles |
| Charge Voltage | 14.6V |
| Cut-Off Voltage | 10V |
| Charge Current | 100A |
| Discharge Current | 100A |
| Peak Discharge Current | 200A |
| Working Temperature | -20~65 (℃)-4~149(℉） |
| Dimension | 260*168*209mm |
| Weight | 14.5Kg |
| Package | One Battery One Carton, Each Battery Protected Well when package |
Advantages
Long Cycle Life
> The battery has a cycle life over 4000 times. Its exceptionally long service life provides sustainable and economical energy for high-energy electric vehicle and energy storage applications.
Safety
> It remains secure even when overcharged or short circuited. It ensures safe operation even in extreme conditions, which is especially important for high-energy vehicle and utility applications.
Fast Charging
> The battery enables rapid charging and massive current discharging. It can be fully recharged in 2 to 3 hours and provides high power output for heavy-duty electric vehicles, industrial equipment and inverter systems with huge loads.
Why Our Power LiFePO4 Batteries
-
10 Years Battery Life
Long battery design life
01 -
5 Years Warranty
Long warranty
02 -
Ultra Safe
Built-in BMS protection
03 -
Lighter Weight
Lighter than lead acid
04 -
More Power
Full capacity, more powerful
05 -
Fast Charge
Support quick charge
06
-
Grade A Cylindrical LiFePO4 Cell
Each cell is Grade A level, clarified as per 50mah and 50mV, bulit-in safe valve, when the internal pressure is high, it would automatically open to protect battery. -
PCB Structure
Each cell has separate circuit, has fuse for protection, in case one cell is broken, the fuse will cut-off automatically, but the complete battery will still working smoothly. -
Expoxy Board Above BMS
BMS fixed on expoxy board, the expoxy board is fixed on PCB, it is very robust struture. -
BMS Protection
BMS has protection from over-charging, over discharging, over current, short circuit and balance, could pss high current, intelligient control. -
Sponge Pad Design
Sponge (EVA)around the module, better protection from shaking, vibration.
